BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant

1. Product Name: Large Pedal Automatic Drain Combined Eyewash
2. Brand: Bohua
3. Model: BH30-5012
4. Production Standards: GBT38144.1/2-2019, US ANSI Z358.1-2014.
5. Function: Eyewash + Shower + Automatic Drain.
6. Nominal Pressure: 1.0 MPa.
7. Operating Pressure: 0.2-0.4 MPa.
8. Eyewash Flow Rate: ≥11.4 L/min.
9. Shower Flow Rate: ≥76 L/min.
10. Inlet Size: 1-1/4" Internal Thread, 102mm Height
11. Outlet Size: 1-1/4" Internal Thread, 102mm Height
12. Gross Weight: 19 kg
13. Net Weight: 17 kg
14. Medium: Domestic water at room temperature that meets hygienic standards.
15. Main Material: 304 stainless steel
16. Eyewash nozzle: Fixed soft rubber dust cover prevents loss, and the soft rubber design prevents eye injuries. A built-in multi-layer filter effectively filters impurities from the water, creating a foamy flow.
17. This product is suitable for use in winter environments with temperatures as low as -5°C and includes an automatic drain function for antifreeze protection.
18. Suitable for use in a wide range of industries and sectors, including nuclear power, power plants, pharmaceuticals, medical treatment, chemicals, petroleum, shipbuilding, electronics, smelting, printing and dyeing, education, and scientific research.
